Cut Motor Energy Costs by 20–50% with a Reliable VFD
Pre-engineered variable frequency drives for pumps, fans, compressors and conveyors — soft starts, precise speed control and a payback you can calculate before you buy.
High energy bills
Motors run at full speed, 24/7
Water hammer & surge
DOL starts shock pipes and valves
Motor damage & downtime
High inrush current shortens motor life
35% energy saved
Speed follows real demand
14-month payback
ROI calculated from your duty cycle
Smooth soft start
No surge, longer pump & motor life
20–50% ↓
12–24 mo
500 +
ONE SOLUTION, EVERY INDUSTRY —
APPLICATION NAVIGATOR
Find Your Drive by Application
Skip the guesswork — start from your application, not the datasheet. Each lane leads to pre-matched series, sizing guides and archived models.
Water & Wastewater
Soft starts and constant pressure for pumps, aeration blowers and lift stations.
HVAC & Building
AHU fans, cooling towers and chiller pumps that cut energy use in part-load.
Oil & Gas & Mining
Rugged drives for conveyors, crushers, mud pumps and ESPs in harsh sites.
General Industry
From extruders to winders — general-purpose and high-performance control.
CERTIFICATION & QUALITY
Quality You Can Verify
Genuine products, verified credentials and factory-level inspection on every unit we ship.
- Brand & Sourcing
Authorized agent for the manufacturer — genuine, traceable products sourced directly from the factory. Every supply channel is formal to eliminate counterfeit risk for your project.
- Quality Control
100% pre-shipment inspection — each unit is burn-in tested, parameter-verified and individually packed with full documentation.
18-Month Warranty on every unit
· full manufacturer-backed support, plus free online engineering assistance for sizing and commissioning.
CERTIFICATION & QUALITY
Quality You Can Verify
Genuine products, verified credentials and factory-level inspection on every unit we ship.
| Dimension | EconomyBG-E · budget class | GeneralBG-G · all-round | High-PerformanceBG-HP · DTC / vector | Medium-VoltageBG-MV · 3–10 kV | Soft StarterBG-SS · SCR ramp | Motor ProtectionBG-MP · add-on |
|---|---|---|---|---|---|---|
| Power Range | 0.4–22 kW | 0.4–315 kW | 0.75–400 kW | 3–10 kV / 100–2000 kW | 7.5–500 kW | 0.4–315 kW |
| Control | V/F | V/F + Sensorless vector | Closed-loop vector / DTC | V/F + Vector | SCR voltage ramp | — |
| Communication | RS485 Modbus | Modbus · CANopen | Modbus · Profinet · EtherCAT | Modbus · Profibus | — | Modbus |
| Protection | IP20 | IP20 / IP54 | IP20 / IP54 | IP54 | IP00 / IP54 | IP20 |
| Typical Application | Pumps, small fans | General industry, HVAC | Precision torque, cranes, winders | Large pumps, fans, mills | DOL replacement, pumps | Motors needing protection |
| Best For | Budget & standard jobs | All-round choice | Premium control | High-power retrofit | Smooth starts on a budget | Add-on motor safety |
| Price Level | $ | $$ | $$$ | $$$$ | $$ | $ |
Need help matching a series? Send your motor nameplate — we reply with a matched drive and quotation within 24 hours.
TIER DECISION
Standard Tier or Premium Tier?
Same brand, two engineering tiers — pick the one that fits your load profile and budget.
SCENARIO DECISION GUIDE
When to choose Standard: for pumps, fans and other variable-torque loads, Standard Tier delivers the same running performance with a lower TCO. When to choose Premium: for extruders, winders and other high-precision torque applications, Premium Tier’s DTC technology remains the safer, more stable choice.
📊 5-Year TCO Comparison
Variable torque load · energy + purchase + maintenance
Data based on a simulated energy model under typical operating conditions; actual TCO varies with load type, running hours and electricity price.
☰ Dimension Comparison
Premium vs Standard · 8 dimensions
| Dimension | Premium Tier | Standard Tier | Best For |
|---|---|---|---|
| Control | DTC / closed-loop vector | V/F + sensorless vector | Precision torque → Premium Variable torque → Standard |
| Overload | 110–150% HD | 110% HD | Heavy-duty start → Premium Normal load → Standard |
| Communication | Profinet · EtherCAT · Modbus | Modbus RS485 | Factory integration → Premium |
| Certification | Full series CE / UL | Core series CE / UL | Mandatory cert projects → per requirement |
| Efficiency | Up to 98% | Up to 97% | Maximum energy saving → Premium |
| Lead Time | 8–16 weeks | 2–6 weeks (in stock) | Emergency replacement → Standard |
| Environment | IP54 option · coated PCBA | IP20 standard | Harsh / dusty sites → Premium |
| Price Level | Higher capex, lower lifetime cost | Lowest entry cost | Budget-sensitive project → Standard |
CHALLENGES → SOLUTIONS
Common Challenges, Solved
Real motor-control problems you face on site — and the drive configuration that fixes them.
Water hammer when pumps start and stop
Direct-on-line starts send pressure surges through the pipe network, cracking joints, stressing pumps and tripping alarms on every cycle.
SOLUTION
Soft-start ramp + built-in PID pressure control
RESULT
ressure spikes eliminated · pump and seal life extended
Related Case →
Motors overheating in high ambient temperature
Hot environments force derating and can trip the drive mid-production — losing you output exactly when cooling demand is highest.
SOLUTION
Derating-curve-matched selection + coated PCBA option
RESULT
Stable rated output up to 50°C · fewer unplanned stops
Related Case →
Harmonics tripping upstream breakers
Non-linear loads distort the supply, nuisance-trip shared distribution equipment and can void warranty on sensitive neighbours.
SOLUTION
Built-in DC choke + optional external harmonic filter
RESULT
THDi below 10% · no more nuisance trips on shared feeders
Related Case →
Motor burnout from repeated DOL starts
High inrush current heats motor windings on every start; frequent cycling quickly shortens insulation life and drives repair cost.
SOLUTION
Current-limited ramp with thermal-model motor protection
RESULT
Inrush cut by up to 60% · insulation and bearing life extended
Related Case →
Success Stories
Real Projects, Real Results
Measurable outcomes from drives we shipped and supported — energy saved, downtime cut, output raised.
- High-inrush motor starts on plant pumps & compressors risk voltage dips and mechanical shock
- 10 Xichi CMV-10 series MV soft starters (355–1313 A) for pumps & compressors
MV soft starters installed
10
Initial voltage setting
30%
- Harmonics from medium-frequency furnaces tripping capacitor banks & overheating transformers
- Two Xichi XCAPF-3L/100A active power filters (APF)
voltage THD after
4%
APF rated current
100 A
- High inrush current & mechanical stress on large gas compressor starts
- Xichi CMV-630-10 10kV soft starter for natural gas compressor
Current limit setting
300% Ie
Start ramp time
15 s
F A Q
VFD Questions, Answered
The questions buyers ask before they send a quote request.
Q1 — What's the difference between a VFD and a soft starter?
A soft starter ramps voltage to limit starting current, but the motor keeps running at full speed. A VFD varies both voltage and frequency, giving full speed control — which is what unlocks energy savings on pumps and fans. Use a soft starter when you only need smooth starts; use a VFD when you need speed control or energy savings.
Q2 — How do I size a VFD for my motor?
Send us your motor nameplate: voltage, rated current (FLA), power and your application. For constant-torque loads (conveyors, extruders) we usually match or slightly oversize the drive; for variable-torque loads (pumps, fans) the drive is matched to the motor FLA. We confirm a model and quotation within 24 hours.
Q3 — How much energy can a VFD actually save?
On variable-torque loads, savings of 20–50% are typical because energy falls with the cube of speed. Actual savings depend on your duty cycle, running hours and electricity price — send us your operating profile and we will run a quick payback estimate with you.
Q4 — How long do VFDs last?
With a clean supply and reasonable ambient temperature, a quality drive typically runs 10–15 years. The main wear component is the DC-link capacitors, usually replaced after 8–10 years. Our drives include full thermal management and surge protection to maximise service life.
Q5 — Do you support OEM orders and custom lead times?
Yes. Standard Tier models ship from stock in 2–6 weeks; custom and OEM orders (logo, firmware defaults, communication options) run 8–16 weeks depending on configuration. We quote lead time in writing with every order and keep a buffer stock for urgent replacements.
Q6 — What maintenance does a drive need?
Minimal: keep it clean and dry, check fans and terminals during annual inspection, and plan a capacitor check around year 8. We provide a simple maintenance checklist with every shipment and free online support for commissioning and troubleshooting.
Q7 — Can a VFD run any motor?
Most standard three-phase AC induction motors can run on a VFD, provided voltage, current and insulation class are compatible. For special motors (submersibles, explosion-proof, servo, single-phase) the drive selection differs — send us the motor details and we will confirm compatibility before you order.
